This multifunction cycling time relay is designed for applications that require repeated ON/OFF switching at adjustable intervals. It is ideal for room ventilation, cyclic dehumidification, automatic lighting control, circulating pumps, advertising signs, and other equipment that needs periodic operation. The relay offers two cycling modes—Cycling Start with Pulse and Cycling Start with Pause—allowing users to select the most suitable operation pattern for their system. With simple knob adjustment, stable output performance, and DIN rail installation, this relay provides a reliable solution for both residential and industrial timing tasks.
| Technical parameters | S1 S2 |
| Function | Asymmetric cycler time relay |
| Supply terminals | A1-A2 |
| Voltage range | AC/DC 12-240V(50-60Hz) |
| Burden | AC 0.09-3VA/DC 0.05-1.7W |
| Supply indication | green LED |
| Time ranges | 0.1s-10days,ON,OFF |
| Time setting | potentionmeter |
| Current rating | 16A/AC1 |
| Mounting/DIN rail | Din rail EN/IEC 60715 |
| Dimensions | 90x18x64mm |
Suitable for pump decay time after switching heating off, switching of fans. Time scale 0.1 s-10 days.
Designed for specific function requirements. Time switch for periodic ventilation and cooling.
